Powering smartly through your paperwork, this compact all in one printer can print, copy, scan and fax. Immaculate 1,200 dpi output is produced at speed. The first print is ready in under six seconds and multipage sets are delivered at a productive 43 ppm. The 10.1 inch Smart Operation Panel automates time-consuming document processes. Double-sided originals are scanned in a single pass and can be uploaded directly to DropBox™ or Sharepoint™.
COMMISSION REGULATION (EU) 2019/2020. The light source of this product is not intended for applications other than image printing.
- B&W printing
- 43 PPM
- Features and benefits
The impressive functionality and performance of the IM 430F can be shared by workgroup users. Documents can be printed directly from iOS and Android devices. To safeguard security, the all in one printer supports tap and go authentication and confidential documents can be locked, pending release. Switching seamlessly between the optional paper trays, it need never run out of paper. And, thanks to its space-saving design and quiet operation, the IM 430F can be placed within easy reach of workgroup users.
- Smartly manages all document processes, including fax communication
- Super-sized 10.1 inch Smart Operation Panel simplifies operation
- Smart apps, such as ID Card Copy, automate time-consuming processes
- Eliminating bottlenecks, the first 1,200 dpi print is ready in under six seconds
- Multipage document sets can be neatly finished using the offline stapler option
- Energy-saving features reduce power consumption and contribute to a low total cost of ownership
- Supports use of integrated workflow solutions, such as Ricoh StreamLine NX
GENERAL Warm-up time 22 seconds First output speed: B/W 4.5 seconds Continuous output speed 43 ppm Memory: standard 2 GB Memory: maximum 2 GB HDD: standard 320 GB HDD: maximum 320 GB SPDF capacity 50 sheets Weight 30.5 kg Dimensions: W x D x H 476 x 442 x 510 mm Power source 220 - 240 V, 50 - 60 Hz COPIER Multiple copying Up to 999 copies Copy resolution: maximum 600x600 dpi Zoom From 25% to 400% in 1% steps PRINTER CPU Intel Atom Processor Bay Trail 1.46GHz Printer language: standard PCL5e, PCL6, PostScript 3 (emulation), PDF direct (emulation) Printer language: option Genuine Adobe® PostScript®3™, IPDS, PDF Direct from Adobe® Print resolution: maximum 1,200 x 1,200 dpi Network interface: standard Ethernet 10 base-T/100 base-TX/1000 base-T, USB Host 2.0 Network interface: option Bi-directional IEEE 1284, Wireless LAN (IEEE 802.11a/b/g/n), Additional NIC (2nd port) Mobile printing capability Apple AirPrint, Mopria®, Google Cloud Print, NFC, Ricoh Smart Device Connector Network protocol TCP/IP (IP v4, IP v6) Windows® environments Windows® 7, Windows® 8.1, Windows® 10, Windows® Server 2008, Windows® Server 2008R2, Windows® Server 2012, Windows® Server 2012R2, Windows® Server 2016 Mac OS environments Macintosh OS X v10.10 or later UNIX environments UNIX Sun® Solaris, HP-UX, SCO OpenServer, RedHat® Linux, IBM® AIX, Citrix XenApp SAP® environments SAP® R/3®, SAP® S/4® Other supported environments NDPS Gateway, AS/400® using OS/400 Host Print Transform, IBM iSeries SCANNER Scanning speed: SPDF 43.4 ipm (simplex)/80 ipm (duplex) Resolution: maximum 1,200 dpi File formats Single Page TIFF, Single page JPEG, Single page PDF, Single page High compression PDF, Single page PDF/A, Multi page TIFF, Multi page PDF, Multi page High compression PDF, Multi page PDF/A Scan modes E-mail, Folder, USB, SD Card FAX Circuit PSTN, PBX Transmission speed 2 seconds Modem speed: maximum 33.6 Kbps Compression method MH, MR, MMR, JBIG Scanning speed 28 spm Memory: standard 4 MB, (320 pages) Memory: maximum 4 MB, (320 pages) PAPER HANDLING Recommended paper size - Standard paper tray(s): A4, A5, A6, B5, B6 Recommended paper size - Optional paper tray(s): A4, A5, A6, B5, B6 Recommended paper size - Bypass tray: A4, A5, A6, B5, B6, Custom Size paper Paper input: standard 500 sheets Paper input: maximum 2,100 sheets Paper output: standard 250 sheets Paper weight - Trays: 52 - 220 g̸ m² Paper weight - Bypass: 52 - 256 g̸ m² Paper weight - Duplex: 52 - 162 g̸ m² Paper types Plain paper, Recycle paper, Special paper, Color paper, Letterhead, Preprinted paper, Envelope, Label paper, OHP ECOLOGY Power consumption: max. Less than 1,290 W Power consumption: operation 625 W Power consumption: ready 91.5 W Power consumption: sleep 0.79 W TEC* 0.55 kWh⁄week CONSUMABLES Starter toner 17,400 prints Drum 70,000 sheets Toner (black) 17,400 prints
