IM 4510
- A3 mono 45 ppm print, copy, scan and fax
- Scan at industry-leading speeds of up to 300 ipm
- Automatic security updates with RICOH Always Current Technology
- Typical Energy Consumption (TEC) 0.44 kWh
Fast A3 black-and-white printing for busy offices
High-performance printing, sustainability built in
The RICOH IM 4510 balances high output with responsible energy use. Up to 50% of the mainframe incorporates recycled materials, while low-melt toner technology helps reduce energy consumption during operation.
With a Typical Energy Consumption (TEC) value of 0.44 kWh, it supports energy-saving goals even in high-output environments.
High-speed output for shared environments
With 45 ppm print speeds, the RICOH IM 4510 delivers reliable A3 performance for busy departments that need consistent document output.
Optional finishing includes a 3,000-sheet finisher with stapling, saddle stitching and hole punching, plus an internal multi-fold unit for in-line folding of brochures, booklets and mail-ready documents.
Comprehensive security and device control
The RICOH IM 4510 includes advanced security features to protect documents, users and data across shared print and scan environments. Flexible administrator settings, modern authentication options and centralised controls help organisations manage device access and reduce security risks.
Advanced protections include TPM 2.0 hardware security and encryption for data in transit and at rest to secure device communications. RICOH Always Current Technology delivers ongoing feature and security updates to support compliance and long-term device management.
Device and print management
The RICOH IM 4510 integrates seamlessly with Ricoh’s Office Print Software Solutions portfolio, enabling secure device management, intelligent capture and centralised print control across your organisation.
From automated document routing and OCR-powered data extraction to remote fleet monitoring and cloud-based print management, these solutions help reduce IT complexity, strengthen security and support more efficient document workflows.
22 seconds
3.6 seconds
45 ppm
6 GB
256 GB
1 TB
220 sheets
91 kg
587 x 701 x 963 mm
220 - 240 V, 50 - 60 Hz
Up to 999 copies
600 dpi
From 25% to 400% in 1% steps
3.3 seconds
ApolloLake E3940 1.6 GHz
PCL5e, PCL6, PostScript 3 (emulation), PDF direct (emulation)
Genuine Adobe® PostScript®3™, XPS, PDF Direct from Adobe®
1,200 x 1,200 dpi
Ethernet 10 base-T∕100 base-TX∕1000 base-T, USB Host I∕F Type A, USB Device I∕F Type B, Bluetooth, Wireless LAN (IEEE 802.11 a/b/g/n/ac)
Additional NIC (2nd port)
Apple AirPrint, Mopria®, Ricoh Smart Device Connector
Windows® 10/11, Windows® Server 2016/2019/2022/2025
Macintosh OS X v12 or later
UNIX Sun® Solaris, HP-UX, SCO OpenServer, RedHat® Linux Enterprise, IBM® AIX
IBM iSeries
80 ipm (200-300 dpi)
150 ipm (simplex) - 300 ipm (duplex)
1,200 dpi
Single Page TIFF, Single page JPEG, Single page PDF, Single page High compression PDF, Single page PDF∕A, Multi page TIFF, Multi page PDF, Multi page High compression PDF, Multi page PDF∕A, Single page Encryption PDF, Multi page Encryption PDF, Single∕multi OCR (optional)
E-mail, Folder, USB
PSTN, PBX
G3: approximately 2 seconds (200 x 100 dpi, JBIG, ITUT #1 chart TTI off, memory transmission), G3: approximately 3 seconds (200 x 100 dpi, MMR, ITUT #1 chart TTI off, memory transmission)
33.6 Kbps
8x3.85 line̸ mm, 200x100 dpi
16x15.4 line̸ mm, 400x400 dpi
MH, MR, MMR, JBIG
68 spm
90 spm
4 MB (320 pages)
60 MB (4,800 pages)
SRA3, A3, A4, A5, A6, B4, B5, B6, Envelopes
SRA3, A3, A4, A5, A6, B4, B5, B6, Envelopes
SRA3, A3, A4, A5, A6, B4, B5, B6, Envelopes, Custom Size paper: Width: 90 mm - 320 mm, Length: 148 mm - 1,260 mm
1,200 sheets
4,850 sheets
500 sheets
3,625 sheets
Paper weight
60 - 300 g∕m²
52 - 300 g∕m²
52 - 256 g∕m²
Plain paper, Recycled paper, Special paper, Colour paper, Letterhead, Cardstock, Preprinted paper, Bond paper, Coated paper, Envelope, Gloss paper, Label paper
< 1,850 W
647 W
37.3 W
0.31 W
0.44 kWh⁄week
* It is a reference value based on the ENERGY STAR Ver.3.2 test method.
1x 550-sheet paper tray, 2x 550-sheet paper tray, 2,000-sheet Large capacity tray, 1,650-sheet side Large capacity tray, 1,000-sheet Hybrid finisher, 3,000-sheet finisher, 1,000-sheet Booklet finisher, 3,000-sheet booklet finisher, 500-sheet Internal finisher, Internal multi-fold unit, Internal shift tray, One-bin tray, Output jogger unit
Fax unit, G3 Interface, Fax memory unit, Cabinet, Caster table, Side Tray, Banner paper guide tray, Punch units, IPDS unit, PostScript 3, Device server unit, File format converter, OCR unit, Page keeper, Imageable area extension unit, ADF handle, Counter I/F unit, Key counter bracket, NFC card reader, Paperlock, Unicode Font Package for SAP, Card reader cover, SSD 1 TB option, Enhanced Security SSD, Bridge unit, XPS, SD card for fonts, Stapleless unit, Antimicrobial screen protector
42,900 prints
Consumable yield based on 5% coverage⁄A4
