IM 3510 / IM 3510A
- A3 mono 35 ppm print, copy, scan and fax
- Scan at industry-leading speeds of up to 300 ipm
- Auto security updates with RICOH Always Current Technology
- Typical Energy Consumption (TEC) 0.34 kWh
High-performance A3 business printing for demanding environments
Sustainable performance with low energy impact
Built for organisations with higher print demands, the RICOH IM 3510 combines strong performance with responsible energy and resource use. The mainframe incorporates up to 50% recycled materials and uses advanced low-melt toner technology to reduce energy consumption during operation.
With a Typical Energy Consumption (TEC) value of 0.34 kWh, it supports more intensive usage while helping you manage energy efficiency and running costs.
Advanced security and simplified fleet control
The RICOH IM 3510 is designed to protect documents, users and data across busy print and scan environments. Flexible admin roles and modern authentication options can help reduce risk and support compliance requirements.
Advanced protections include TPM 2.0 hardware security, data encryption at rest and in transit, plus, enhanced SSL/TLS encryption help to secure device communications.
Through RICOH Always Current Technology, the device will receive ongoing feature and security updates to maintain security standards and manage devices without manual intervention.
Intelligent cloud print management
As an available add-on for the IM 3510, RICOH CloudStream centralises and secures print infrastructure in the cloud, creating a scalable foundation for intelligent document processing and automated workflows.
Professional finishing, in-house
Enhance document output with versatile finishing options, including stapling, staple-free binding, hole punching and multi-folding.
The optional inner folding unit supports multiple fold types and folds up to three sheets, making it ideal for preparing invoices, mailings and other ready-to-send documents.
22 seconds
4.5 seconds
35 ppm
6 GB
256 GB
1 TB
100 sheets
220 sheets
83 kg
83 kg
90 kg
587 x 701 x 913 mm
587 x 701 x 963 mm
220 - 240 V, 50 - 60 Hz
Up to 999 copies
600 dpi
From 25% to 400% in 1% steps
4 seconds
ApolloLake E3930 1.3 GHz
ApolloLake E3940 1.6 GHz
PCL5e, PCL6, PostScript 3 (emulation), PDF direct (emulation)
Genuine Adobe® PostScript®3™, XPS, PDF Direct from Adobe®
1,200 x 1,200 dpi
Ethernet 10 base-T∕100 base-TX∕1000 base-T, USB Host I∕F Type A, USB Device I∕F Type B, Bluetooth, Wireless LAN (IEEE 802.11 a/b/g/n/ac)
Additional NIC (2nd port)
Apple AirPrint, Mopria®, Ricoh Smart Device Connector
Windows® 10/11, Windows® Server 2016/2019/2022/2025
Macintosh OS X v12 or later
UNIX Sun® Solaris, HP-UX, SCO OpenServer, RedHat® Linux Enterprise, IBM® AIX
IBM iSeries
80 ipm (200-300 dpi)
150 ipm (simplex) - 300 ipm (duplex)
1,200 dpi
Single Page TIFF, Single page JPEG, Single page PDF, Single page High compression PDF, Single page PDF∕A, Multi page TIFF, Multi page PDF, Multi page High compression PDF, Multi page PDF∕A, Single page Encryption PDF, Multi page Encryption PDF, Single∕multi OCR (optional)
E-mail, Folder, USB
PSTN, PBX
G3: approximately 2 seconds (200 x 100 dpi, JBIG, ITUT #1 chart TTI off, memory transmission), G3: approximately 3 seconds (200 x 100 dpi, MMR, ITUT #1 chart TTI off, memory transmission)
33.6 Kbps
8x3.85 line̸ mm, 200x100 dpi
16x15.4 line̸ mm, 400x400 dpi
MH, MR, MMR, JBIG
68 spm
90 spm
4 MB (320 pages)
60 MB (4,800 pages)
SRA3, A3, A4, A5, A6, B4, B5, B6, Envelopes
SRA3, A3, A4, A5, A6, B4, B5, B6, Envelopes
SRA3, A3, A4, A5, A6, B4, B5, B6, Envelopes, Custom Size paper: Width: 90 mm - 320 mm, Length: 148 mm - 1,260 mm
1,200 sheets
4,850 sheets
500 sheets
1,625 sheets
Paper weight
60 - 300 g∕m²
52 - 300 g∕m²
52 - 256 g∕m²
Plain paper, Recycled paper, Special paper, Colour paper, Letterhead, Cardstock, Preprinted paper, Bond paper, Coated paper, Envelope, Gloss paper, Label paper
< 1,700 W
486 W
35.4 W
0.31 W
0.34 kWh⁄week, * It is a reference value based on the ENERGY STAR Ver.3.0 test method.
* It is a reference value based on the ENERGY STAR Ver.3.2 test method.
1x 550-sheet paper tray, 2x 550-sheet paper tray, 2,000-sheet Large capacity tray, 1,650-sheet side Large capacity tray, 1,000-sheet Hybrid finisher, 3,000-sheet finisher, 1,000-sheet Booklet finisher, 3,000-sheet booklet finisher, 500-sheet Internal finisher, Stapleless internal finisher, Internal multi-fold unit, Internal shift tray, One-bin tray, Output jogger unit
Fax unit, G3 Interface, Fax memory unit, Cabinet, Caster table, Side Tray, Banner paper guide tray, Punch units, IPDS unit, PostScript 3, Device server unit, File format converter, OCR unit, Page keeper, Imageable area extension unit, ADF handle, Counter I/F unit, Key counter bracket, NFC card reader, Paperlock, Unicode Font Package for SAP, Card reader cover, SSD 1 TB option, Enhanced Security SSD, Bridge unit, XPS, SD card for fonts, Stapleless unit, Antimicrobial screen protector
30,100 prints
Consumable yield based on 5% coverage⁄A4
