Ri4000
- Printable Area: 406 x 498 mm (maximum with optional large platen)
- Resolution: Super Fine: 1200 x 1200 dpi / 16 pass
- Dimensions (W x D x H): 882 x 1662 x 500 mm
Advanced Digital Textile Printer
Intelligent Maintenance and Integrated Support
The printer is always primed and ready to go with its intelligent automatic cleaning system and automatic white ink agitation. This reduces manual maintenance and ensures consistent print readiness.
The QR codes on the touchscreen panel, on the other hand, provide instant access to online support videos, making maintenance even more easy.
Sustainable and ECO Passport Certification
The RICOH Ri 4000 is designed with sustainability in mind.
Its water-based pigment inks are ECO PASSPORT certified by OEKO-TEX®. This certification means the inks are safe for you to work with and safe for your customers to wear. By choosing the Ri 4000, you are promoting sustainable production and can proudly highlight your environmental credentials.
Produce vibrant, soft-touch apparel
The RICOH Ri 4000 is engineered for speed, precision, and durability, utilising genuine Ricoh piezo-electric print heads to deliver high-quality, vibrant graphics. It can print in super high-resolution, up to 1200 x 1200 dpi, without sacrificing speed.
With its unique dual-carriage print heads, the Ri 4000 optimises the position and size of ink droplets, ensuring faithful reproduction of designs with rich colours and fine details.
Related software
Grow your business with ColorGate Solution
For ultimate colour accuracy, the printer can be bundled with ColorGATE Textile Production Server (TPS) software. This software allows for accurate colour management and can process even the largest design files faster than ever before. The drop-on-demand technology ensures the inks are absorbed into the fabric, imparting a soft, luxurious feel to the finished garments.
Direct to Garment printer
Ricoh piezo-electric drop on demand inkjet system
RICOH print head
92 seconds
1,200 x 1,200 dpi
406 x 498 mm
45 - 70%
18 - 25°C
882 x 1,662 x 500 mm
135 kg
220 - 240 V, 50/60 Hz
320 W
Water-based pigment ink
Cyan, Magenta, Yellow, Black, White
Windows 10
Ethernet 10Base-T/100Base-Tx/1000BASE-T, USB flash drive
2 GHz
4 GB
120 GB
Small platen, Medium platen, Large platen
