Ricoh Interactive Whiteboard A6500
The A6500 Ricoh Interactive Whiteboard is designed with a feature-rich suite of tools built-in to give you the ultimate collaboration solution for your organisation. With the easy-to use interface this new whiteboard offers seamless communication, ideal for hybrid working powerful learning, allowing multiple people to write on the same screen.
- Features and benefits
-
Key features
- Android embedded built-in
- Expandable with Windows controller
- A set of pre-installed applications
- Simple connectivity
- Wired & wireless content sharing
'With remote learning and collaboration now a part of most classrooms and lectures, hybrid classrooms need to allow real-time participation and information sharing with in person and remote attendees. The A6500 Ricoh Interactive Whiteboard is designed for business and built for education being affordable, intuitive and customisable.Quickly browse the web, or launch an app at the tap of a finger or pen. Easily navigate IFPD menus, tools, functions, and apps through the customisable home screen and intuitive toolbar. Annotate on documents and save them directly to the board or the cloud for later use - all built-in as standard. - Specifications
-
GENERAL Rear interface HDMI IN x2: Version: HDMI2.0, Up to 3840x2160@60HzHDMI1 support ARC function, HDCP 1.4/2.0/2.2 compliant, DP IN x1: Version: DP1.2a, Up to 3840x2160@60Hz, HDCP 1.4/2.2 compliant, VGA IN x1: Interface: DB15, Up to 1920x1080@60Hz , Audio IN x1: Interface: Φ3.5mm mini interface, input level(L/R): 0.2-2Vrms, LAN x2: 10M/1000Mbps Base-T, 100Mbps Base-TX, Support internet switch, To OPS(10M/100M/1000M), To Android(10M/100M), Interface: RJ-45 , USB2.0 x1: Support images, music, video file playback, only can use this USB port to upgrade, Interface: USB2.0 Type-A , USB3.0 x2: Support images, music, video file playback. Upgrade are not supported, Interface: USB3.0 Type-A , Touch-USB x1: Touch interface for HDMI1/HDMI2/DP/VGA, Interface: USB3.0 Type-B , MIC IN x1: Can Mix the MIC input and other input source to SPK OUT, Interface: Φ3.5mm mini interface, SPDIF x1: Max speed: 16Mbps, Interface: Optical , RS232-IN x1: RS232 Input, Interface: DB9 , HDMI-OUT x1: Max. resolution: 3840x2160@60Hz, Version: HDMI2.0, All signals can be Loop-outed by HDMI-OUT , Audio OUT x1: Output level(L/R): 10mVrms±40mVrms (@500mVrms 1KHz, load 32Ω), Interface: Φ3.5mm mini interface (Headphone-out) Front interface Type-C x1: Power output: 20V/3A, Up to 3840x2160@60Hz, Interface: Type-C , Public USB x2: Version: USB3.0, Interface: Type-A , Touch-USB x1: Touch interface for HDMI, Interface: USB3.0 Type-B , HDMI IN x1: Version: HDMI2.0, Up to 3840x2160@60Hz, HDCP 1.4/2.0/2.2 compliant RAM 4 GB ROM (storage) 32 GB Dimensions: W x D x H (mm) 1,511.6 x 87.8 x 920.3 Package size: W x D x H (mm) 1,660 x 220 x 1,010 Weight (kg) 39 Package weight (kg) 54 Housing material (face frame/back shell) Aluminium/metal plate Housing colour (face frame/back shell) Black/black VESA 4-M8 screw hole 600 x 400 mm DISPLAY PANEL Panel size: diagonal (" wide) 65 Effective area: W x H (mm) 803.52 x 1,428.48 Resolution: maximum (Full HD) 3,840 x 2,160 Colours: maximum 1,070,000,000 Brightness: maximum (cd/m²) 350 Contrast ratio 1,200 : 1 Pixel pitch (mm) 0.372 x 0.372 Response: grey to grey (ms) 8 Refreshing frequency 60 Hz Viewing angle: H/V (°) 178/178 LED lifetime 50,000 hours Colour gamut 72% TOUCH SYSTEM Sensing type Infrared touch frame Surface protection 3.2 mm toughened glass Infrared touch Up to 20 points Interpolation resolution 32,768 x 32,768 Theory clicks Unlimited Connect type USB2.0 Full Speed Voltage DC+5V +/- 5 % Windows 10/8/7, Android Multiple touch supported Windows XP, Linux, Mac OS X, Chrome Single touch supported ELECTRICAL Power requirements AC 100V - 240V, 50/60Hz Power consumption without OPS Maximum brightness: 300 W, 50% brightness: 180 W Standby condition without OPS < 0.5 W Audio output power 2x15 W / 8 Ω OPS power DC 18V / 5A SOFTWARE OS Android 9.0 Pre-installed app Whiteboard, Browser, File manager, Screen share, Office document view (incl. PDF), Media Player, Cloud storage, Android app store Default functions Welcome screen (Launcher), Setting, Source setting, Annotation tool, Stopwatch, Clock, Calculator, Eye-protection, Spotlight, Screen capture, Calendar, Vote, Screen Recorder, Split Screen, Picture in Picture WIFI Operating frequency 2.4 GHz / 5 Ghz Wi-Fi standard 802.11a/b/g/n/ac OPS SPECIFICATIONS Main spec (OPS) Chipset: SOC, LAN interface (Wired): 10BASE-T/ 100BASE-TX/ 1000BASE-T, LAN interface (Wireless): 802.11 ac/a/b/g/n/ax, Network authentication (Wireless LAN): According to setting on system OS, Encryption (Wireless LAN): According to setting on system OS, Interface (Output): HDMI, Interface (others): USB 3.0 Type A x 2,USB 2.0 Type A x 2, USB Type C x 1, 3.5 mm microphone jack, 3.5 mm headphone jack, Bluetooth: embedded, Power Source: DC +12 to 19V Capture box Not included Installation Insert into OPS slot Product size: W x D x H (mm) 200 x 119 x 30 Product weight (kg) 1 Environmental condition Operating temperature limits: -10 - 50°C, Operating humidity limits: 20 - 80%, Storage temperature limits: -10 - 50°C, Storage humidity limits: 15 - 80% ECOLOGY Operating temperature (°C) 0 - 32 Operating humidity (%) 20 - 80 Altitude limitation: sea level (m) Lower than 3,500 Maximum daily operation hours (exclude stand-by time) 18 hours / day (24 hours)Maximum daily operating hours are 18hrs/day. Do not use the machine continuously / intermittently for more than 18 hours per day. Failure to do so could result in malfunction. Storage temperature -10℃ ~ +50℃ Storage humidity 15% ~ 80% RH Non-Condensing Shelf life 14 months after production
